V400-H Series

last update: December 19, 2013

• Designed for easy use on production lines

• Stable reading from a wide variety of objects

• Bringing greater visibility to 2D code reading

• Variable field of vision

• Display customizing function

• Versatile LCD display patterns

last update: December 19, 2013

last update: September 24, 2012

Item	V400-H111	V400-H211
Field of vision	5 × 5 to 10 × 10 mm	15 × 15 to 30 × 30 mm
Cell size	0.08 to 0.2 mm	0.2 to 0.65 mm
Code size	0.8 × 0.8 to 5 × 5 mm	2.0 × 2.0 to 15 × 15 mm
Working distance	40 mm (flush when Contactor is mounted)
Power supply	5 VDC ±10%
Current consumption	1.0 A max.
Serial interface	RS-232C
Applicable codes	Data Matrix, ECC200, 10 × 10 to 64 × 64, 8 × 18 to 16 × 48, QR Code (Models 1, 2), 21 × 21 to 57 × 57 (Versions 1 to 10)
Operation method	Pressing the trigger button
Settings	Make settings by using the manual setting window, uploading from an SD Memory Card, or by using Support Software.
Memory card	SD Memory Card
Monitor	1.8-inch TFT LCD, displaying images and read data
Display illumination	Operation display, memory card access
Ambient temperature	Operation: 0 to 40°C; storage: -25 to 60°C
Ambient humidity	35 to 85% (with no condensation)
Ambient conditions	No corrosive gases
Vibration resistance	10 to 150 Hz, single amplitude 0.35 mm (50 m²/s max. acceleration)
Shock resistance	150 m²/s in ±X, Y, and Z directions, 3 times
Weight	Approx. 230 g
Degree of protection	IEC 60529 IP64
Materials	Case: ABS; optical surface: PC; display surface: PMMA

last update: September 24, 2012
