Power Controllers
SPC1 Series
Brand:
Single-phase power controller SPC1 series supporting various input specification realizes diverse functions including Out ADJ(Limit the output) function and soft Start function(Except for ON/OFF control type). In addition, the series contributes to user convenience by adopting mode switch to select various control types including phase control type, cycle control type (Zero Cross) and ON/OFF control type (Zero Cross)

  • DC4-20mA, 1-5VDC, External 24VDC
  • External adjuster(1kΩ)
  • External contact(ON/OFF)
  • Out ADJ (output limit) function
  • Soft Start function (except for ON/OFF control type)
  • Out display function
  • 50/60Hz automatic converting function
  • Phase control type
  • Cycle control type(zero cross turn-on)
  • ON/OFF control type(zero cross turn-on)

TITLE DOCUMENT TYPE SIZE
SPC1 series Catalog 537 KB
SPC series Manual 570 KB
