Autonics, LP-S044 Series
Logic Panel
LP-S044 Series
Brand:
Highly economical solution for PLC function incorporated touch screen Logic panel LP-S044 Series realizes cost effective and easy operation solution by incorporating HMI, PLC and I/O modules in one body. Also, the series is capable of controlling and monitoring for external controllers thru built-in PLC's communication function; in addition, 16 points of I/O can be controlled through LP main body. Along with high capacity memory of 8,000 steps, PC graphic editor and PLC logic program are also supported to increase user convenience.


Compact structure : Reducing cost, space saving and easy operation through PLC+HMI+Input/ output integration
Improved compatibility with logic : 8000-step program capacity (the average processing speed 6 to 7μs/step) basic command 28, application command 220
Wide device range : Peripheral device 10K word, data device 10K word, and other various devices
Sufficient external I/O : Input 16 points, output 16 points(basic)
Various expansion function : External interrupt, 16-key input, 7 Seg. time-sharing display and synchronous communication output.
Easy software upgrade at website :
(1) LP firmware file (2) GP Editor(drawing program)
(3) Smart Studio(logic program) (4) Additional protocol
● Displays max. 400 characters
● Enables to save max. 500 pages of user screen
Different devices monitoring function : PLC port allows to monitor and control the variables of additionally connected controllers
Supports multilingual : Supports for Korean, Japanese, English, Chinese, Russian, Vietnamese and Portuguese. Additional languages will be available by firmware.
Supports multi-font : It provides various bitmap and user-selected fonts.
Various multi-communication ports : Both RS232 2 port and RS232/RS422 compound port are provided.
Device monitoring function : It enables to monitor LP device and connected controller devices by LP without graphic design data.
Printer and barcode reader connection : It enables to print alarm history connecting a printer and read barcode connecting a barcode reader.
