Long Read Range: The MS-890 optics were engineered for successful reading at extended or varying distances, such as a safety or clearance zone required around conveyor or assembly areas.
Visible Indicators: Illuminated LEDs on the MS-890 provide instant visual confirmation of successful reads. A “good read green flash” is projected from the front window and is visible within a 360 degree radius from the scanner.
Optional Wiring Box: The IB-890 wiring box provides easy and flexible integration, without any special cables or connectors.
Ethernet (with optional MS-Connect 210)
Pluggable relay modules
Terminal strip connectivity.
Connectivity with handheld scanners.
Intelligent Raster: The MS-890 features an intelligent raster which can be optimized for scan angle and speed to read multiple symbols or inconsistently placed labels.
Autocalibration: The autocalibration feature automatically determines and selects optimal read settings for focus, gain and tracking.
Barcode Programming: Changing scanner configuration on the factory floor is as simple as presenting a barcode and pushing the EZ button. This feature makes it simple to replicate settings on multiple MS-890 scanners.
Length: 3.5" (88 mm)
Width: 5" (127 mm)
Height: 6" (152 mm)
Weight: 5 lbs. (227 g)
Type: Semiconductor visible laser diode (650 nm nominal)
Operating life: 50,000 hours @ 25° C (77° F)
Safety class: CDRH Class II
Scanner mirror type: Rotating, single line, 14-faceted mirror
Scan rate: Adjustable from 400 to 1000 scans/second (default = 500 sps)
Raster Sweep Speed: 1 to 30 sweeps per second
Raster Sweep Angle: 30° maximum
Scan Width Angle: Typically 60°
Pitch Angle: ±50° maximum
Skew Angle: ±40° maximum
Label contrast: 25% min. absolute dark to light differential at 650 nm wavelength
Interface: RS-232, RS-422/485, Daisychain/auxiliary port capable, Dedicated configuration port
Interface with IB-890 Wiring Box (optional): Ethernet
