High performance, simple connectivity, and IP54 enclosure make the QX-830 an ideal industrial barcode scanner for any industrial application.
Quick Connect System: M12 connectors and cordsets. Plug and play setup. Single or multi-scanner solutions.
X-Mode Technology: Decodes damaged, poorly printed, or misaligned codes. Ensures high read rates and throughput.
High Performance: Aggressive decoding capabilities allow reliable reading of barcodes out to 30” (762 mm), at up to a 10” (254 mm) beam width.
Real-time Feedback: Visible LED indicators on the side of the scanner and a “good read” green flash projecting from the front window provide confirmation of the scanner’s performance. The green flash is visible within a complete 360 degree radius from the scanner.
Ethernet Protocols: The QX-830 includes optional embedded Ethernet TCP/ IP and EtherNet/IP for high speed communication.
Flexibility: The compact size of the QX-830 allows flexible positioning for a variety of applications.
Depth: 2.59" (66 mm)
Width: 3.47" (88 mm)
Height: 1.38" (35 mm)
Weight: 7.5 oz. (212 g)
Interface: RS-232/422/485 or Ethernet Symbologies
Standard: Code 39, Codabar, Code 93, Interleaved 2 of 5, Code 128, PDF417, Micro PDF417, Pharmacode, UPC, GS1 Databar
Applications Standard: UCC/EAN-128, AIAG Laser Light
Type: Laser diode
Output Wavelength: 655 nm nominal
Operating Life: 50,000 hours @ 25° C
Safety Class: Visible laser: CDRH Class II, 655 nm Scanning Parameters
Mirror Type: Rotating, 10-faceted
Optional Raster Mirror Image: 10 raster scan lines over a 2° arc (or 0.500" raster height at 8" [203 mm] distance)
Scan Rate: Adjustable from 300 to 1400 scans/sec; default is 500 scans/sec
Scan Width Angle: Typically 60°
Pitch: ±50° max. Skew: ±40° max.
Label Contrast: 25% min. absolute dark to light differential at 655 nm wavelength Protocols
Point-to-Point, Point-to-Point w/RTS/CTS, Point-to-Point w/XON/XOFF, Point-to-Point w/RTS/CTS & XON/XOFF, Multidrop, Daisy Chain, User-Defined Multidrop, Ethernet TCP/IP, EtherNet/IP
