Analog Fiber Amplifiers
BF3R Series
Brand:
BF3R Series, a fiber optic amplifier with built-in twin jog-dials, features precise control of sensitivity using coarse-dial and fine-dial. This series offers fast and accurate sensing performance with fast response speed of under 1ms. Also, this series employs free-cut type fiber optic cables where the cable length can be adjusted to the work environment needs.

* Convenient DIN rail mounting type
* Response time : Max. 1ms
* Enables to adjust sensitivity with high accuracy by dual adjuster
* Selectable Light ON/Dark ON operation mode by control wire
* Reverse power polarity and short-circuit(Overcurrent) protection circuit
* Enables to use for explosion proof(Fiber part)
* Adjustable length with free cut type fiber optic cable

TITLE DOCUMENT TYPE SIZE
Fiber Optic Sensors (Applications) Catalog 144 KB
Fiber Optic Sensors (Technical Description) Catalog 709 KB
Fiber Optic Sensors (Product Overview) Catalog 1614 KB
Fiber Optic Sensors (Ordering Information) Catalog 240 KB
Fiber Optic Cable Catalog 1946 KB
BF3R Series Catalog 472 KB
Fiber Optic Sensors Selection Guide Manual 2006 KB
BF3RX Series Manual 375 KB
