Autonics, BF4R Series
Home > Product > Sensing Solutions > Optical Fiber Sensors > BF4R Series
Digital Fiber Amplifiers
BF4R Series
Brand:
BF4R, a high performance fiber optic amplifier, features a compact structure designed to fit into narrow spaces. This fiber optic amplifier has fast response speed of under 0.5ms, and can be compactly mounted. Also, external synchronization input function, mutual interference protection and self-diagnosis function enhance user experience.

* High speed response : Max. 0.5ms
* Auto sensitivity setting(Button setting)/Remote sensitivity setting
* External synchronization input, mutual interference protection, self-diagnosis
* Reverse power polarity and short-circuit(Overcurrent) protection circuit
* Timer function : Selectable None / 40ms OFF Delay timer(fixed) (standard type, remote sensitivity setting type only)
* Automatically selectable Light ON / Dark ON
* Precise detection of small target and easy to install in the complicated place

TITLE DOCUMENT TYPE SIZE
Fiber Optic Sensors (Applications) Catalog 144 KB
Fiber Optic Sensors (Technical Description) Catalog 709 KB
Fiber Optic Sensors (Product Overview) Catalog 1614 KB
Fiber Optic Sensors (Ordering Information) Catalog 240 KB
Fiber Optic Cable Catalog 1946 KB
BF4R Series Catalog 595 KB
Fiber Optic Sensors Selection Guide Manual 2006 KB
BF4R Series Manual 511 KB
