The single phase solid state relays SR1 series feature compact, universal designs for flexible installation and detachable heatsinks for easier maintenance or replacement. The high dielectric strength of 4000 VAC provides durable and reliable performance in various applications, including heater loads, semiconductor equipment, and motor control.
• Increase user convenience with general and small design
• Superior dielectric strength: 4,000VAC
• Improved reliability by maximizing heat protection efficiency with ceramic board
• Supports Zero cross turn-on/Random turn-on type
• Checks input status by Input LED (green)
