Push-in Interface Terminal Blocks
AFR Series
Brand:
The AFR series interface terminal blocks offer quick and easy connection and feature slim and compact design with 5 mm terminal pitch. The terminal blocks utilize a rising clamp type connection with built-in screws for easy, secure and durable connection. The AFR series can be easily mounted with DIN rail locks or screw/bolt connection and are available in 20-pin, 40-pin, and 50-pin terminal models for diverse applications. The AFR series interface terminal blocks utilize a rising clamp type connection with built-in screws for easy, secure and durable connection. The terminal blocks also feature a slim and compact design with 5 mm terminal pitch. The AFR series can be easily mounted with DIN rail locks or screw/bolt connection and are avail

• Rising clamp type connection method offers simple, easy and durable connection
• Slim and compact design with 5 mm terminal pitch
• Ideal for connector type PLCs and dedicated controller I/O
• DIN rail mount and screw mount methods
• Available in 20-pin, 40-pin, and 50-pin terminal models


TITLE DOCUMENT TYPE SIZE
AFR Series Catalog 734 KB
AFR Series Manual 1150 KB
