Autonics, AFS Series
Home > Product > Switching & Accessories > Relay/SSR & I/O Boards > AFS Series
Interface Terminal Blocks
AFS Series
Brand:
Interface terminal block AFS Series is a compact product of which terminal pitch is 7mm. It is optimized for connector type PLC and dedicated controller I/O and saves space with compact size. Also, the series not only provides convenience for wiring works but also enables to make more wide variety of applications with two types of mounting (DIN Rail, bolt fix).

• Compact interface terminal block - 7mm of terminal pitch
• Optimized for connector type PLC and dedicated controller I/O
• Space saving mounting with compact size
• Two ways of mounting(DIN Rail, bolt fix)
• Supports CJ Series(Connector transmission cable)

TITLE DOCUMENT TYPE SIZE
AFS Series Catalog 784 KB
AFS Series Manual 314 KB
