Slim Connector - Terminal Block Conversion Units
XW2D Series
Brand:
New Slim Connector-Terminal Block Conversion Units.

last update: December 19, 2013

• Mounting area reduced by 35% (in comparison with 40-pole XW2B Units) to contribute to downsizing control panels and automatic equipment.

• Fallout prevention for terminal screws.

• Round or forked crimp terminals can be used.

• Mount to DIN Track or via screws.

Unique DIN Track lock can maintain open status during DIN Track attachment and removal.

• Terminal cover can be locked open.

• Screw terminals are arranged by color in groups of five to simplify counting terminal numbers.

last update: December 19, 2013

TITLE DOCUMENT TYPE SIZE
XW2D Catalog 588 KB
XW2[] Series Table of Connector-Terminal Block Conversion Units and connectable device combinations Catalog 978 KB
